Model |
|
SDJ500 |
SDJ1000 |
SDJ1500 |
Load capacity/rated load |
Q(kg) |
500 |
1000 |
1500 |
Load centre distance |
c(mm) |
600 |
600 |
400 |
Fork height,lowered |
h13(mm) |
90 |
90 |
90 |
Height, mast lowered |
h1(mm) |
1490/2080 |
1490/1720/2080/1838/2080 |
2080 |
Max. lift height |
h3(mm) |
1000/1600 |
1000/1200/1600/2500/3000 |
1600 |
Height, mast extended |
h4(mm) |
1490/2080 |
1490/1720/2080/2925/3420 |
2080 |
Overall length |
l1(mm) |
1655/1705 |
1655/1705 |
1655/1705 |
Overall width |
b1(mm) |
755 |
755/755/755/860/860 |
755 |
Fork dimensions |
s/e/l(mm) |
61/170/1100(1150) |
||
Width overall forks |
b5(mm) |
550 |
550/550/550/580/580 |
550 |
Ground clearance, laden,below mast |
m1(mm) |
25 |
25 |
25 |
Aisle width for pallets 1000×1200 crossways |
Ast(mm) |
2112 |
2112 |
2112 |
Aisle width for pallets 800×1200 lengthways |
Ast(mm) |
1945 |
1945 |
1945 |
Turning radius |
Wa(mm) |
1380 |
1380 |
1380 |
Lift speed,laden/unladen |
mm/time |
25 |
25 |
21 |
Lowering speed,laden/unladen |
mm/s |
Manual control |
||
Service weight |
kg |
185/205 |
183/191/204/280/303 |
236 |
