Model |
|
SDJAS500 |
SDJAS1000 |
Load capacity/rated load |
Q(kg) |
500 |
1000 |
Load centre distance |
c(mm) |
500 |
500 |
Fork height,lowered |
h13(mm) |
70 |
70 |
Height, mast lowered |
h1(mm) |
2000 |
2050 |
Max. lift height |
h3(mm) |
1600 |
1600 |
Height, mast extended |
h4(mm) |
2100 |
2155 |
Overall length |
l1(mm) |
1340/1600 |
1300/1560 |
Overall width |
b1(mm) |
1500 |
1450 |
Fork dimensions |
s/e/l(mm) |
48/100/800(1060) |
30/100/800(1060) |
Width overall forks |
b5(mm) |
745 |
950 |
Round clearance, laden,below mast |
m1(mm) |
25 |
25 |
Aisle width for pallets 1000×1200 crossways |
Ast(mm) |
1975 |
1975 |
Aisle width for pallets 800×1200 lengthways |
Ast(mm) |
1915 |
1915 |
Turning radius |
Wa(mm) |
1200 |
1200 |
Lift speed,laden/unladen |
mm/s |
25 |
25 |
Lowering speed,laden/unladen |
mm/s |
Manual control |
|
Service weight |
kg |
217 |
336 |
